Crossed Tapered Roller Bearing

Crossed tapered roller bearing contains double sets of raceways and rollers which are brought together at right angle with alternate rollers facing in opposite directions. Unlike crossed roller bearing, the rolling elements of Crossed tapered roller bearing are tapered rollers. The height of cross section is similar to single-row bearing, thus the design of bearing housing is simplified. The steep-angle tapered geometry makes the effective span of the bearing much greater than the width of the bearing itself. Crossed tapered roller bearings can carry high overturning moment, thus they are widely used in large hobbling machine, industrial robot, high speed vertical lathe, high precision working table, vertical boring machine, and spindle of grinding machine etc.

What is a Crossed Tapered Roller Bearing?

A Crossed Tapered Roller Bearing is a sophisticated bearing designed to handle complex loads with exceptional precision. Unlike conventional bearings, they have tapered rollers arranged at a 90-degree angle, allowing them to support combined radial and axial loads simultaneously. This unique design makes them ideal for applications where high accuracy, rigidity, and durability are essential.

product-1-1

Why Choose CHG Bearing for Your Crossed Tapered Roller Bearings?

At CHG Bearing, we pride ourselves on being a leading manufacturer and supplier of Crossed tapered roller bearing. Here’s why we are your best choice:

  1. Customization and Solutions: We offer tailored solutions to meet specific working conditions and performance requirements. Whether you need bearings for aerospace, robotics, or medical equipment, we provide customized designs to ensure optimal performance.

  2. 30 Years of Industry Experience: With over three decades in the industry, we have a proven track record of delivering high-quality bearings. Our extensive experience allows us to address diverse needs and challenges effectively.

  3. Innovation and Quality: Our commitment to innovation is reflected in our 50+ invention patents. We adhere to strict quality standards, having achieved ISO9001 quality management system and ISO14001 environmental management system certifications.

For more information or to discuss your specific requirements, contact us at sale@chg-bearing.com.

Technical Specifications

Specification Details
Type Crossed Tapered Roller Bearing
Load Capacity High radial and axial loads
Precision P5, P4, P2
Material chrome steel
Temperature Range -40°C to +120°C
Certification ISO9001, ISO14001
Customization Available for different sizes and applications

Crossed Tapered Roller Bearing Benefits

  • High Load Capacity: Capable of supporting substantial radial and axial loads simultaneously, making them ideal for heavy-duty applications.
  • Enhanced Rigidity: Offers superior rigidity and stability, essential for precision machinery and equipment.
  • Reduced Vibration: Minimizes vibration and noise, contributing to smoother operation and extended equipment life.
  • Durability: Designed to withstand harsh environments, including high temperatures and corrosive conditions.

Applications

  • Aerospace: Essential for the motion mechanisms of aircraft landing gear, missiles, and drones, ensuring reliable operation in extreme conditions.
  • Robotics: Used in industrial robots' motion mechanisms, including arms and joints, to ensure precise and stable movements.
  • Machine Tools: Provides high precision and rigidity in spindle transmission devices and feed systems, crucial for quality machining.
  • Medical Equipment: Supports motion and stability in high-end medical devices like CT and MRI machines, operating reliably in challenging environments.
  • Automobile Manufacturing: Used in steering gears, transmissions, and suspension systems, ensuring performance and durability in vehicles.
  • Other Fields: Includes semiconductor manufacturing and liquid crystal production, where precision and stability are critical.

Installation Guide

  1. Preparation: Ensure that the installation area is clean and free of debris.
  2. Alignment: Properly align the bearing with the mounting surface to avoid misalignment.
  3. Insertion: Gently insert the bearing into the housing or assembly.
  4. Securing: Use appropriate tools to secure the bearing in place, following the manufacturer's specifications.
  5. Testing: Rotate the bearing manually to check for smooth operation and proper alignment.

Maintenance and Care

  • Regular Inspection: Check for signs of wear or damage regularly.
  • Lubrication: Keep bearings properly lubricated to reduce friction and wear.
  • Clean Environment: Maintain a clean operating environment to prevent contamination.
  • Proper Storage: Store bearings in a dry, clean place to avoid rust and damage.

FAQ

Q: What types of loads can a Crossed Tapered Roller Bearing handle?

A: It can handle combined radial and axial loads simultaneously, making it suitable for complex applications.

Q: What is the typical lifespan of a Crossed Tapered Roller Bearing?

A: Lifespan varies based on application conditions, but proper maintenance can significantly extend its life.

Q: Can Crossed Tapered Roller Bearings be customized?

A: Yes, we offer customization to meet specific performance and size requirements.

Q: How should I choose the right bearing for my application?

A: Consider factors such as load capacity, precision, operating environment, and size requirements. Our team can help with recommendations based on your needs.

Customer Reviews

"CHG Bearing's products have transformed our robotics applications. The precision and reliability are unmatched!" – John D., Robotics Engineer

"We rely on CHG for all our aerospace bearing needs. Their expertise and quality are second to none." – Sarah T., Aerospace Engineer

Contact Us

For more information about our Crossed tapered roller bearing or to request a quote, please reach out to us:

Email: sale@chg-bearing.com

Experience precision and performance with CHG Bearing’s products. Contact us today to find the perfect solution for your needs!

Part Number Main dimensions Basic dynamic
load rating
Limiting speed
(Oil)
Weight
(Kg)
Inner ring
(mm)
Outer ring
D(mm)
Width
B(mm)
Chamfer
r(min)
Radial
Cr(KN)
Axial
Ca(KN)
HXR496051 203.2 279.4 31.75 1.5 41 49.2 800 6.5
HXR678052 330.2 457.2 63.5 3 80 98.4 620 35
HXR766051 457.2 609.6 63.5 3 106 133 520 51
HXR820060 580 760 80 5 106 209 300 100
HXR855053 685.8 914.4 79.375 3 180 224 260 150
HXR882055 901.7 1117.6 82.55 3 225 297 200 185
HXR889058 1028.7 1327.15 114.3 3 283 374 160 400
HXR897051 1549.4 1828.8 101.6 3 326 489 80 500
HJXR637050 300 400 37 1.5 47.2 60 720 13
HJXR652050 310 425 45 2.5 61.6 76.5 640 20
HJXR699050 370 495 50 3 70.2 89.2 600 30
