Axial Deep Groove Ball Bearing

1. Details: The thrust ball bearings are classified into two kinds: unidirectional thrust bearing and bidirectional thrust bearing. The former can bear the axial force in one direction and the latter can bear he axial forces in two directions. Both unidirectional and bidirectional thrust ball bearings cannot bear any radial force. Thrust ball bearing can limit axial displacement of shafts or housings in one or two direction, but not radial displacement. Therefore, the bearings are usally used with deep groove ball bearings.
Single direction thrust ball bearing consist of one row of balls ( with cage ), a shaft washer ( close fit with shaft ) and a housing ring ( loose fit with shaft and close fit with bore of bearing block ). They can not carry radial loads but axial loads in one direction, because the axial loads are well distributed on each bal, the loading capacity is higher, but the temperatue is high while working, and their limiting speed is lower.
Double direction angular contact thrust ball bearings are high precision bearings which are specilly designed for spindles of machine toole. They are able to carry axial loads in two directions, and they have more balls with small diameter. The centrifugal influence can be reduced as their 60° contact angle, so more suitable for high speed application.
It can carry axial loads that dimension series 2344 and 2349 double direction angular contact thrust ball bearings fit with dimension series NN30 and NU49 double row cylindrical roller bearings.
Double direction angular contact thrust ball bearings with class SP whose running accuracy is P4 and dimension accuracy is P5 can produced by us.

Send Inquiry Download

What is an Axial Deep Groove Ball Bearing?

Axial deep groove ball bearings are a specialized type of bearing designed to handle axial loads in one direction while allowing for smooth rotation. These bearings are essential in various industrial applications, especially where machinery requires the capacity to handle significant axial forces. Their design includes raceways on both the inner and outer rings, which help accommodate the axial load efficiently. Due to their unique construction, these bearings are often chosen for their durability, precision, and reliability in high-stress environments.

CHG Bearing: Your Trusted Axial Deep Groove Ball Bearing Manufacturer

At CHG Bearing, we take pride in being a leading manufacturer and supplier of axial deep groove ball bearings. With over 30 years of experience in the industry, we’ve partnered with numerous large-scale companies to deliver top-tier bearing solutions. Our expertise is backed by more than 50 invention patents, and we’ve successfully passed ISO9001 quality management, ISO14001 environmental management, and other significant certifications.

We understand the demanding requirements of the metallurgical and mining industries, which is why we offer customized bearing solutions tailored to meet specific working conditions. Whether it’s high precision, long life, or cost-effectiveness, CHG Bearing provides products that align with your needs. For inquiries and custom orders, feel free to contact us at sale@chg-bearing.com.

Technical Specifications

Specification	Details
Bearing Type	Axial Deep Groove Ball Bearing
Load Direction	Axial (Single Direction)
Bore Diameter Range	10 mm – 200 mm
Outer Diameter Range	30 mm – 300 mm
Material	High-Grade Steel
Precision Rating	P0, P6, P5, P4
Sealing Options	Open, Sealed
Lubrication	Grease, Oil
Operating Temperature Range	-30°C to +150°C
Certification	ISO9001, ISO14001

Benefits

High Precision & Rigidity: Our bearings are engineered to provide exceptional precision, which is crucial for the stable operation of machinery and the quality of the end product.
Durability: Built to withstand harsh environments, our bearings offer extended service life, reducing the need for frequent replacements.
Custom Solutions: We offer customization options to meet the specific needs of your equipment, including different sizes, materials, and lubrication methods.
Cost-Effective: Our products offer a perfect balance between high performance and reasonable pricing, ensuring you get the best value.
Fast Delivery: We understand the importance of quick response times in the industry, and we strive to meet urgent delivery requirements.

Applications

Axial deep groove ball bearings from CHG Bearing are widely used across various industries due to their versatility and reliability. Common applications include:

Metallurgical Equipment: Essential for blast furnaces, rolling mills, and steelmaking machinery.
Mining Machinery: Integral in crushers, vibrating screens, and feeders, where they support heavy loads and ensure smooth operation.
Industrial Machinery: Used in various types of rotating equipment, ensuring optimal performance under demanding conditions.

Installation Guide

Proper installation is key to ensuring the longevity and performance of axial deep groove ball bearings. Here are some general steps:

Preparation: Ensure that the bearing housing and shaft are clean and free of any debris.
Mounting: Gently press the bearing onto the shaft or into the housing using a press tool or appropriate equipment, avoiding direct impact.
Alignment: Ensure that the bearing is correctly aligned with the shaft and housing to prevent uneven load distribution.
Lubrication: Apply the recommended lubricant (grease or oil) to reduce friction and wear.
Testing: After installation, rotate the shaft by hand to ensure smooth movement and correct installation.

Maintenance and Care

Inspection: Periodically check for signs of wear, corrosion, or damage.
Lubrication: Regularly apply the appropriate lubricant to minimize friction and extend bearing life.
Cleaning: Remove any debris or contaminants from the bearing and surrounding area to prevent damage.
Replacement: Replace bearings at the first sign of significant wear to avoid unexpected equipment failure.

FAQ

Q1: What makes axial deep groove ball bearings suitable for high-stress environments?

A1: Their unique design allows them to handle significant axial loads efficiently while maintaining smooth rotation, making them ideal for high-stress applications.

Q2: Can CHG Bearing customize bearings for specific applications?

A2: Yes, we offer customization options to meet the specific requirements of different industries and working conditions.

Q3: How do I know which bearing size to choose for my equipment?

A3: Our technical team is available to assist you in selecting the right bearing size based on your equipment’s specifications and operating conditions.

Q4: What are the common signs that a bearing needs replacement?

A4: Common signs include unusual noise, increased vibration, and difficulty in rotation, indicating wear or damage.

Q5: What kind of after-sales support does CHG Bearing offer?

A5: We provide comprehensive after-sales support, including technical assistance, replacement parts, and maintenance advice.

Customer Reviews

"CHG Bearing's axial deep groove ball bearings have significantly improved our equipment's performance. The precision and durability are unmatched, and the customization options have been a game-changer for our operations." - John D., Technical Engineer

"The quick delivery and high-quality bearings from CHG have made them our go-to supplier. Their bearings have reduced our maintenance downtime significantly." - Mary T., Production Manager
