Double Row Ball Slewing Bearing

1. Type: External gear, Internal gear, No gear
2. Size: For No Gear Type
Inner Diameter: 260-4272mm ,Outer Diameter: 480-4726mm
Weight: 55-4000kg
For Internal Gear Type
Inner Diameter: 458-4272mm ,Outer Diameter:662-4726mm
Weight: 94-4000kg
For External Gear Type
Inner Diameter: 470-4272mm ,Outer Diameter: 694-4726mm
Weight: 93.1-4000kg
3. Feature: Four-point contact ball slewing bearings contact angle is usually 35°. If there is only a radial load, each steel ball contacts the raceway at four points. If there is only a unidirectional axial load, each steel ball contacts the raceway at two points. It can bear axial loads in two directions as well as a certain eccentric load, i.e. torque. Such kind of bearing has features and properties of both single-row and double-row angular contact ball bearings. If it is used in a high-speed scenario, two-point contact must be ensured for its normal working.
4. Material:50Mn/42CrMo/S48C/42CrMo4/16Mn

What is a Double Row Ball Slewing Bearing?

A Double Row Ball Slewing Bearing is a critical component in various types of machinery and equipment, known for its robustness and versatility. This bearing consists of two rows of balls separated by a raceway, providing high load capacity, durability, and smooth rotational movement. It’s commonly used in applications where both axial and radial loads are present, along with moments of force.

Why Choose CHG Bearing for Your Double Row Ball Slewing Bearing Needs?

CHG Bearing stands out as a leading manufacturer and supplier of Double Row Ball Slewing Bearings. Here's why:

Customization and Solutions: We offer tailored solutions to meet diverse working conditions, ensuring optimal performance for your specific needs.
Industry Experience: With 30 years of expertise in the bearing industry, we have established strong relationships with numerous large companies.
Innovative Edge: Our portfolio includes over 50 invention patents, reflecting our commitment to innovation.
Certifications: We adhere to rigorous quality standards, evidenced by our ISO9001 Quality Management System and ISO14001 Environmental Management System certifications.

Technical Specifications

Specification	Details
Outer Diameter	[Specify Range] mm
Inner Diameter	[Specify Range] mm
Width	[Specify Range] mm
Load Capacity	[Specify Load] kN
Material	High-quality Steel
Seals	Rubber/Metal Seals
Temperature Range	[Specify Range] °C
Certifications	ISO9001, ISO14001

Benefits of Double Row Ball Slewing Bearings

Enhanced Load Capacity: Handles both radial and axial loads efficiently.
Smooth Rotation: Provides consistent and smooth rotational movement.
Durability: Designed to withstand harsh conditions and heavy loads.
Versatility: Suitable for a wide range of applications, from construction machinery to aerospace equipment.

Applications

Double Row Ball Slewing Bearings are indispensable in various industries:

Construction Machinery: Essential in excavators, loaders, bulldozers, and more for load-bearing and rotation.
Lifting Machinery: Used in tower cranes, gantry cranes, and truck cranes to enhance rotational stability.
Wind Power Generation: Supports the rotation of wind turbine cabins for optimal wind energy collection.
Oil Drilling: Ensures stable operation under high-load conditions in drilling rigs.
Military Equipment: Improves mobility and combat performance in tanks and armored vehicles.
Port Terminals: Facilitates efficient loading and unloading in cranes and gantry cranes.
Agricultural Machinery: Enhances operation in harvesters and tractors.
Medical Equipment: Enables rotation in MRI machines and other diagnostic tools.
Amusement Facilities: Allows smooth rotation in carousels and Ferris wheels.
Aerospace: Ensures stable rotation in satellites and rockets.
Other Fields: Utilized in material processing, transportation machinery, and automated production lines.

Installation Guide

Preparation: Ensure the installation area is clean and free from debris.
Alignment: Properly align the bearing with the mounting surface.
Mounting: Secure the bearing using appropriate fasteners, ensuring uniform torque.
Verification: Check the rotation and alignment before putting the equipment into operation.

Maintenance and Care

Regular Inspections: Check for signs of wear, damage, or irregular noise.
Lubrication: Keep the bearing well-lubricated according to the manufacturer's recommendations.
Cleaning: Regularly clean the bearing and surrounding area to prevent contamination.
Adjustments: Make necessary adjustments to ensure proper alignment and functionality.

FAQ

Q: What industries use Double Row Ball Slewing Bearings?
A: They are used in construction machinery, lifting equipment, wind turbines, oil drilling, military equipment, and more.

Q: How do I choose the right size?
A: Consider the load capacity, diameter, and application requirements. Consult with our experts for personalized recommendations.

Q: What maintenance is required?
A: Regular inspections, lubrication, and cleaning are essential for optimal performance and longevity.

Q: Can you provide custom solutions?
A: Yes, we offer customization to meet specific operational needs.

Customer Reviews

“The bearings from CHG Bearing have exceeded our expectations in terms of performance and durability. Highly recommended!”
— John D., Construction Machinery Specialist

“CHG Bearing’s expertise and quality are unmatched. Their slewing bearings have been reliable in our wind turbines.”
— Sarah K., Wind Power Engineer

Contact Us

For more information or to request a quote, please contact us at sale@chg-bearing.com. Our team is ready to assist you with all your Double Row Ball Slewing Bearing needs.
